| Threaded Nozzle G1/2 for Hose 9 mm | CADPDFRFQ |
Preview
Threaded Nozzle G1/2 for Hose 9 mm
Threaded Nozzle G1/2, CuZn, nickel-plated Flat gasket DIN 7603-A 21×26, Al
Scope of Delivery
Threaded Nozzle G1/2, CuZn, nickel-plated Flat gasket DIN 7603-A 21x26, Al
Properties
| line 8 | line 8 |
|---|---|
| ESD-safe | No |
| Weight | m = 58 g |
| Delivery unit | 1 set |
The Threaded Nozzle creates a tight connection between a central compressed-air line and the integrated compressed air duct of the item installation profiles. In order to make this connection, it is necessary to tap a G 1/2" hole in the installation profiles.
